Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min

Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min
Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min

Large Image :  Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min

Product Details:
Place of Origin: China
Brand Name: Eagle
Certification: ISO9001:2000
Model Number: CK6136/500mm/750mm/1000mm
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Harden wood case
Delivery Time: within 35days
Payment Terms: 30% by T/T in advnce,70% pay against the copy of B/L.
Supply Ability: 10set/month
Detailed Product Description
High Light:

horizontal cnc lathe machine

,

cnc horizontal lathe machine

Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min







CK6136/500mm/750mm/1000mm CNC Lathe (Heavy-Duty type) processing for Internal or external diameter,face,taper,ARC and threading with high efficiency.Spindle speed changed by frequency and standard tool post is 4-stations.

CK6136 CNC Lathe (Heavy-Duty type)
Features:

  1. The machine can process precisely internal or external diameter, face, taper, ARC and threading with high efficiency.
  2. Standard tool post is 4-stations, also 6-stations tool post can be optioned.
  3. Spindle speed changed by frequency.
  4. Induction for harden bed-way. Bed saddle with plastic sticker can improve the accuracy and service life of the machine.
  5. The spindle is supported by imported precision bearing.
  6. Normally machine is provided with 3-jaw chuck, also according to customer’s required will be equip Hydraulic chuck or pneumatic chuck.

Quick Details

Condition:
New
Place of Origin:
Anhui,China (Mainland)
Brand Name:
Eagle
Model Number:
CK6136/500mm/750mm
/1000mm
Type:
Horizontal
CNC or Not:
CNC
Voltage:
220V,380V
Power(KW):
3KW
Dimension(L*W*H):
1850×1100×1650mm
1900x1100x1650mm
2300x1100x1650mm
Weight:
1400/1500/1600kgs
Certification:
ISO9001:2000
Warranty:
one year


Main parameter and specifications:


SPECIFICATION
ITEM CK6136/500mm CK6136/750mm CK6136/1000mm
Swing over bed Φ360mm Φ360mm Φ360mm
Swing over carriage Φ150mm Φ150mm Φ150mm
Taper of spindle Through hole Through hole Through hole
Spindle bore Φ51mm Φ51mm Φ51mm
Range of speed(variable) 100~2500r/min 100~2500r/min 100~2500r/min
Feed motor power(X/Z) 4N.M/6N.M 4N.M/6N.M 4N.M/6N.M
X rapid traverse 6m/min 6m/min 6m/min
Z rapid traverse 6m/min 6m/min 6m/min
Max. travel of X axis 170mm 170mm 170mm
Max. travel of Z axis 400mm 650mm 900mm
Motor power 3Kw 3Kw 3Kw
Tool-post 4 stations 4 stations 4 stations
Max.tool size 16×16mm 16×16mm 16×16mm
Min input unit 0.001mm 0.001mm 0.001mm
repeatability accuracy(X/Y) 0.016mm 0.016mm 0.016mm
Barrel travel of tailstock 130mm 130mm 130mm
Barrel taper of tailstock M.T.3 M.T.3 M.T.3
Packing size(L×W×H) 1850×1100×1650mm 1900×1100×1650mm 2300×1100×1650mm
N/G Weight 1400kg 1500 1600kg
Loading amount 6pcs/20' container 6pcs/21' container 5pcs/22' container




Standard accessories:

  1. 3-jaw chuck and tool post and wrench.
  2. Allen wrench
  3. Electrical tool post(4-station)
  4. Cooling system
  5. Manual lubrication system
  6. Working lamp
  7. GSK CNC controller system.
.
Optional accessories:

1. 6-station tool post.

2. Pneumatic chuck.

3. Hydraulic chuck.

4. Controller system: SIEMENS802S and 802C.

5. Atuo-lubrication system.

6.Bar auto-feeding device(only for model CK6136)


Advantage:
1. Professional make it for years and have a rich experience.
2. Good relationship team for study and development.
3. Good reputation from the customer in the world.

 Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min 0Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min 1
