Product Details:
|
| Model: | ST-2500 | Power Supply: | AC220V ; 50Hz |
|---|---|---|---|
| Suitable Cap Diameter: | Φ10mm~Φ60mm | Production Capacity: | 0~22meters /minutes |
| Gas Feed: | 0.5Mpa Stable Gas Feed | ||
| High Light: | liquid filling line,Filler line |
||
Automatic cap electromagnetic induction aluminum foil sealer
Quick Detail:
1.Two Twins Hoppers with high speed and accuracy.
2. Filling weight range:100-2000g.
3. High output: 80-100 cans/min.
Description:
This sealer takes the electromagnetic induction principle as a basis, makes the aluminum foil produce bow wave and become heat. Then the membrane under aluminum foil will melt and adhesion to the opening of the PE&PET bottles, and then to make bottles sealed. The high stress resistance components are quite reliable and the parameter specifications are wide. It can be widely used for the sealing of abnormal bottles and big size mouth bottles. The circulating water makes cooling. The machine don’t need touch the bottle caps just cowling outside while sealing, GMP audit requirement can be conformed.
1. Suitable cap diameter: Φ10mm~Φ60mm
2. Suitable bottle height: 40mm—245mm (May custom-tailor)
3. Production Capacity: 0~22meters /minutes
4. Machine Weight: about 200kg
5. Machine Dimension: 950mm x850mm x1550mm
Specifications:
|
Model |
ST-2500 |
|
Power supply |
AC 220V; 50HZ |
|
Power |
2.5Kw |
|
Suitable cap diameter |
40mm—245mm (May custom-tailor) |
|
Suitable cap diameter |
Φ10mm~Φ60mm |
|
Production Capacity |
0~22meters /minutes |
|
Machine Weight |
about 200kg |
|
Machine Dimension |
950mm x850mm x1550mm |
Competitive Advantage:
|
1 |
Our machines are reputed for high accuracy. |
|
2 |
Unique with respect to container interchangeability with minimum size parts. |
|
3 |
Quick change over, minimum down time and highly operator friendly. |
|
4 |
Custom built for the Food and packaging Processing Industry. |
|
5 |
Microprocessor controls with human – machine interface and touch screen controls. |
|
6 |
Can achieve filling speeds upto 300 containers per minute. |
Picture show:
