| Hardness: | More Than HRC43 | Material: | Chrome Molybdemun Alloy Steel |
|---|---|---|---|
| Impact Value: | AK≥100J | Model No.: | DF692 |
| Inspection: | UT&MT | Surface Quality: | Good Surface Quality After Shot Blasting |
| High Light: | alloy steel forging,cast iron steel |
||
Chrome Molybdemun Alloy Steel Castings With Hardness More Than HRC43
1 Impact value:AK≥100J.
2 Hardness difference from surface to center is less than HRC2.
3. The steel liners have higher reliability in AG mills and SAG mills.
4 The Pearlitic Cr-Mo Alloy Steel mill liners are widely used for AG mills, SAG mills, large ball mills.
The general advantages in ball mills are as follows:
|
Output Increased |
5~20% |
|
Power Consumption Reduced |
5~20% |
|
Maintenance Decreased |
Above 98% |
|
The liners are easily installed and existing mills need no modification. |
|
The additional advantages in cement mills are as follows:
|
No leakage of slurry |
|
No repairs during service periods |
|
Better reliability and stability |
|
Production Improvement |
|
Noise reduction |
Technical Parameters
Wuxi Orient Anti-wear Engineering Co., Ltd.
Chemical Composition & Mechanical Property of Wear-resistant Castings
|
Item |
Cr-Mo Alloy Steel I |
Cr-Mo Alloy Steel II |
Cr-Mo Alloy Steel III |
High Cr white iron |
High Cr Alloy Steel |
High Manganese Steel |
Ni-Hard cast iron |
|
C |
0.30~0.50 |
0.65~0.90 |
0.40~0.90 |
2.40~3.20 |
1.1~2.2 |
0.90~1.30 |
2.40~3.60 |
|
Si |
0.50~1.20 |
≤0.75 |
0.70~1.20 |
0.60~1.20 |
0.60~1.20 |
≤0.08 |
≤0.80 |
|
Mn |
0.40~1.20 |
0.50~1.20 |
0.60~1.00 |
0.50~1.00 |
0.50~1.00 |
11.00~18.00 |
≤2.0 |
|
Cr |
1.70~2.50 |
1.50~2.50 |
4.00~7.00 |
12.00~30.00 |
11.00~30.00 |
1.50~2.50 |
1.5~10 |
|
S |
≤0.04 |
≤0.06 |
≤0.04 |
≤0.04 |
≤0.04 |
≤0.04 |
≤0.15 |
|
P |
≤0.04 |
≤0.06 |
≤0.06 |
≤0.06 |
≤0.06 |
≤0.06 |
≤0.15 |
|
Mo |
≤0.5 |
≤0.5 |
≤0.5 |
0.10~3.0 |
0.10~3.0 |
≤1.0 |
≤0.10 |
|
Cu |
0.10~0.60 |
≤0.25 |
0.20~0.40 |
0.10~1.00 |
0.10~1.00 |
- |
- |
|
Ni |
≤0.50 |
≤0.30 |
0~0.30 |
0~0.30 |
0~0.30 |
- |
3.3~10 |
|
Re |
≤0.02 |
≤0.02 |
≤0.02 |
- |
- |
- |
- |
|
Equivalent Specifications |
DL/T 681-1999
GB/T26651-2011 |
AS 2074 L2B Mod |
DL/T 681-1999 |
GB/T 8263-1999 AS 2027 Cr27 AS 2027 CrMo 15/3 AS 2027 CrMo 20/2/1 ASTM A532 Class III type A 25% Cr ASTM A532Class II type B 15% Cr-Mo BS 4844 3E DIN1695 NFA32401. |
GB/T 5680-1998 DL/T 681-1999 JIS G 5153-1999 ASTM A 128 DIN GX120Mn12 AFNOR:Z120Mn12 |
GB/T 8263-1999 AS 2027/Ni-Cr1-550 AS 2027/Ni-Cr2-500 AS 2027/Ni-Cr4-500 AS 2027/Ni-Cr4-600 AS 2027/Ni-Cr4-630 ASTM A 532 1-A,B,C,D ASTM A 532 2-A,B,C,D,E ASTM A 532 3-A |
|
|
Material Type |
Martensite Steel |
Martensite or Pearlitic Cr Mo Steel |
Martensite Steel |
Martensite matrix |
Austenitic Mn Steel |
- |
|
|
Hardness |
HRc≥48 |
HB470 & HB 321~370 |
HRc≥50 |
HRc≥56 |
HB≤300 |
HRc≥56 |
|
|
Impact Value |
Ak≥40J |
- |
Ak≥10J |
Ak≥4J |
Ak≥80J |
- |
|
Our foundry has complete melting,heat treatment and test equipments,such as mid frequency induction
electrical furnaces, quenching and tempering furnaces, blast shot, spectrometer,Rockwell and Brinell
Hardness tester,impactor,UT tester and metallographic microscope.We achieved the certificate of
quality management system ISO 9001:2000.We have been exporting castings to oversea markets,such
as Brazil,Australia and South Africa.
Our foundry has complete melting,heat treatment and test equipments,such as mid frequency induction
electrical furnaces,quenching and tempering furnaces,blast shot,spectrometer,Rockwell and Brinell
Hardness tester, impactor,UT tester and metallographic microscope.We achieved the certificate of
quality management system ISO 9001:2000.We have been exporting castings to oversea markets,such
as Brazil, Australia and South Africa.
