25KW Induction Melting Equipment

25KW Induction Melting Equipment
25KW Induction Melting Equipment 25KW Induction Melting Equipment 25KW Induction Melting Equipment 25KW Induction Melting Equipment

Large Image :  25KW Induction Melting Equipment

Product Details:
Place of Origin: China
Brand Name: GY
Certification: CE, SGS , ROHS
Model Number: GYM-100KW
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden box
Delivery Time: Depend on the order and destination
Payment Terms: TT
Supply Ability: 500set/month
Detailed Product Description
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Online Support,Video Technical Support,Field Installation Warranty: 1 Year
Duty Cycle: 100%,24 Hours No-stop Application: Melting
Certification: CE, FCC, ROHS
High Light:

IGBT induction heater


induction melting furnace

100KW Induction Melting Equipment For Smelting Aluminum , Bronze, Copper, steel, gold, silver 50KG


Quick Detail:



100KW Induction Melting furnace by auto, manual


Smelting steel, iron, aluminum, bronze, copper, steel, gold, silver and other precious metals

Work power

360V - 480V 3Phase

Out power


Model Number








Model: GYM-100KW

Max output power: 100KW

Smelting weight of steel, iron: 50kg

Smelting weight of aluminum, bronze, and other precious metals: 100kg



Smelting weight of steel and iron

Smelting weight of alumium, bronze, and other precious metals
























Major features


1. Medium frequency induction heating machine adopts solid state IGBT frequency conversion control technologies, it has all kinds of protection control, giving signal under conditions of over-current, water shortage, overheating, overvoltage, short circuit, and phase missing, as a result, the reliability is greatly enhanced.

2. It has the function display of current, voltage, and timing, making the working condition easily perceived, and giving guidance to induction coil design, capacitance control.

3. Small size, light weight, requires no more than 1 sqm, and movable

4. Continuously heating for 24 hours

5. Low power consumption, with electromagnetic grinding capability, providing uniform smelting



Operating Principle


Frequency conversion electromagnetic induction heating or induction heating for short is a method for heating metal materials by converting power frequency power supply into that of specific range based on the principle of electromagnetic induction. It is mainly applicable to the metal hot working, heat treatment, welding and melting. This type of heating technique is also applicable to packing industry (such as sealing of aluminum foil used in medicine and food industry), semiconductor material (such as extruded monocrystalline silicon and heated affixing metal parts for auto glass).

Basic components of induction heating system include induction coil, AC power source and work pieces. Induction coil can be fabricated into different shapes as per different heated objects. The coil is connected with the power source providing alternating current for coil. The alternating current possessed by the coil can create a alternating magnetic field passing through the work pieces to produce eddy flow as required by heating.



Advantages of Induction Heating Equipment


1. Fast heating: the minimum rate of heating is less than 1 second (rate of heating is available for adjustment and control).

2. Wide coverage of heating: it can be used to heat various metal parts (replace removable induction coil as per different operating switches).

3. Easy installation: it can be used once it is connected with power source, induction coil as well as water supply pipe and rising pipe; it is small in size and light in weight.

4. Easy operation: you can learn to operate it within several minutes.

5. Fast start-up: it can be started to perform heating operation on condition that water and power supply is available.

6. Low power consumption: As compared with conventional vacuum tube high frequency equipments, it can save the power by approximately 70%. The smaller the size of the work piece is, the lower power consumption would be.

7. High effectiveness: it has such features as uniform heating (it is applicable to adjust the spacing of the induction coil to ensure the appropriate temperature as required by each part of work piece), fast warming and limited oxic horizon, and can guard against any waste after annealing.

8. Comprehensive protection: it has such functions as overpressure, over-current, overheat and water shortage alarm indications as well as automatic control and protection.

9. Controllable temperature: it is applicable to control the temperature for heating work pieces as per the preset heating time, and thereby control the heating temperature at a certain technical point.

10. Comprehensive full load design: it can work continuously for 24 hours.

11. Small size and light weight: it has a weight of only several dozens of kilograms, of which, the limited floor space can effectively save the workshop space.

12. Elimination of high voltage: it requires no step-up transformer which may produce approximately ten thousand voltage, and thus can ensure the maximum safety.
